BB Ball Nose End Mill 3 & 4 Flute Solid Carbide R0.5–R10 | Finishing

BB Ball Nose End Mill – 3 & 4 Flute Solid Carbide (BF2055 / BB2055)

Precision-ground solid carbide ball nose end mills optimized for semi-finishing and finishing of complex 3D contours and mold cavities. Choose between 3-flute and 4-flute geometry based on your workpiece material.

Which Series Should I Choose?

Series	Flutes	Best For	Advantage
BF2055	3 Flute	Aluminum, non-ferrous metals	Larger chip clearance, prevents built-up edge, excellent surface finish on Al
BB2055	4 Flute	Steel, stainless steel, hardened steel	Higher rigidity, better surface finish on ferrous materials

Key Features

Material: Ultra-fine grain solid carbide
Coating: TiAlN / AlTiN (high heat & wear resistance)
Radius range: R0.5 – R10 mm (diameter Ø1 – Ø20 mm)
Neck lengths: 50 / 60 / 75 / 100 / 150 mm
Application: Finishing & semi-finishing of 3D profiles, die & mold, contour milling

Specification Guide

Naming convention: R[radius]x[neck length] — e.g., R2x50 = radius 2 mm (Ø4 mm), neck length 50 mm

Radius (R)	Diameter (D)	Available Neck Lengths
R0.5	Ø1 mm	50, 75 mm
R0.75	Ø1.5 mm	50 mm
R1	Ø2 mm	50, 75 mm
R1.25	Ø2.5 mm	50 mm
R1.5	Ø3 mm	50 mm
R1.75	Ø3.5 mm	50 mm
R2	Ø4 mm	50, 75, 100 mm
R2.25	Ø4.5 mm	50 mm
R2.5	Ø5 mm	50, 75, 100 mm
R3	Ø6 mm	50, 75, 100, 150 mm
R4	Ø8 mm	60, 75, 100, 150 mm
R5	Ø10 mm	75, 100, 150 mm
R6	Ø12 mm	75, 100, 150 mm
R7	Ø14 mm	100 mm
R8	Ø16 mm	100, 150 mm
R9	Ø18 mm	100 mm
R10	Ø20 mm	100 mm

Shipping

Orders ship within 3 business days. Standard airmail available; express shipping recommended for urgent orders. Contact us if your order has not arrived within 60 days.

BB Tool – Professional manufacturer of precision carbide cutting tools.
